I found this a little while ago and noticed that there is no header – so I don’t know who wrote it. Whoever it was – thank you!!
Update: I found the original postings of this code:
This little routine quickly detaches all XREFS from a drawing. XREFS are not limited to other drawing files. Pictures and PDFs are also considered XREFS. This routine will detach all of these as well.
Here’s how:
- DETACHALL <enter>
- That’s it. the routine will remove all XREFs
;;; BY VVA found at cadtutor.net
;;; Also posted by Azarko at https://forums.augi.com/showthread.php?131322-LISP-to-detach-all-XREF-PDF-IMAGE-ALL-UNDERLAYS/page2
(defun C:Detachall (/ *error*
mip:layer-status-restore mip:layer-status-save
delete-xref-img-underlay delete-all-dict
)
(vl-load-com)
(defun *error* (msg)
(mip:layer-status-restore)
(princ msg)
(princ)
) ;_ end of defun
(defun mip:layer-status-restore ()
(foreach item *PD_LAYER_LST*
(if (not (vlax-erased-p (car item)))
(vl-catch-all-apply
'(lambda ()
(vla-put-lock (car item) (cdr (assoc &quot;lock&quot; (cdr item))))
(vla-put-freeze
(car item)
(cdr (assoc &quot;freeze&quot; (cdr item)))
) ;_ end of vla-put-freeze
) ;_ end of lambda
) ;_ end of vl-catch-all-apply
) ;_ end of if
) ;_ end of foreach
(setq *PD_LAYER_LST* nil)
) ;_ end of defun
(defun mip:layer-status-save ()
(setq *PD_LAYER_LST* nil)
(vlax-for item (vla-get-layers
(vla-get-activedocument (vlax-get-acad-object))
) ;_ end of vla-get-layers
(setq *PD_LAYER_LST*
(cons (list item
(cons &quot;freeze&quot; (vla-get-freeze item))
(cons &quot;lock&quot; (vla-get-lock item))
) ;_ end of cons
*PD_LAYER_LST*
) ;_ end of cons
) ;_ end of setq
(vla-put-lock item :vlax-false)
(if (= (vla-get-freeze item) :vlax-true)
(vl-catch-all-apply
'(lambda () (vla-put-freeze item :vlax-false))
) ;_ end of vl-catch-all-apply
) ;_ end of if
) ;_ end of vlax-for
) ;_ end of defun
(defun delete-xref-img-underlay (/ count txt)
(mip:layer-status-save)
(vlax-for Blk (vla-get-Blocks
(vla-get-activedocument (vlax-get-acad-object))
) ;_ end of vla-get-Blocks
(if (and (= (vla-get-IsXref Blk) :vlax-false)
(not (wcmatch (vla-get-name Blk) &quot;*|*&quot;))
) ;_ end of and
(progn
(setq count 0
txt (strcat &quot; Erase Xref and Underlay in &quot;
(vla-get-name Blk)
) ;_ end of strcat
) ;_ end of setq
(grtext -1 txt)
(vlax-for Obj Blk
(setq count (1+ count))
(if (zerop (rem count 10))
(grtext -1 (strcat txt &quot; : &quot; (itoa count)))
) ;_ end of if
(if
(and (vlax-write-enabled-p Obj)
(or
(and ;_ XREF
(= (vla-get-ObjectName obj) &quot;AcDbBlockReference&quot;)
(vlax-property-available-p Obj &quot;Path&quot;)
) ;_ end of and
(and ;_ UNDERLAY
(wcmatch (vla-get-ObjectName obj) &quot;*Reference&quot;)
(vlax-property-available-p Obj &quot;UnderlayName&quot;)
) ;_ end of and
(= (vla-get-ObjectName obj) &quot;AcDbRasterImage&quot;) ;_ IMAGE
) ;_ end of or
) ;_ end of and
(VL-CATCH-ALL-APPLY 'vla-Delete (list Obj))
) ;_ end of if
) ;_ end of vlax-for
) ;_ end of progn
) ;_ end of if
) ;_ end of vlax-for
(mip:layer-status-restore)
) ;_ end of defun
(defun delete-all-dict (dict)
;;; dict - dict name (like &quot;ACAD_IMAGE_DICT&quot;, &quot;ACAD_PDFDEFINITIONS&quot; ... )
(vl-catch-all-apply
'(lambda ()
(vlax-map-Collection
(vla-item
(vla-get-dictionaries
(vla-get-activedocument (vlax-get-acad-object))
) ;_ end of vla-get-dictionaries
dict ;_ &quot;ACAD_IMAGE_DICT&quot;
) ;_ end of vla-Item
'vla-delete
) ;_ end of vlax-map-Collection
) ;_ end of lambda
) ;_ end of vl-catch-all-apply
) ;_ end of defun
(vl-load-com)
(delete-xref-img-underlay)
(command &quot;_-xref&quot; &quot;_d&quot; &quot;*&quot;)
(while (&gt; (getvar &quot;CMDACTIVE&quot;) 0) (command))
(mapcar 'delete-all-dict
(list &quot;ACAD_IMAGE_DICT&quot;
&quot;ACAD_PDFDEFINITIONS&quot;
&quot;ACAD_DWFDEFINITIONS&quot;
&quot;ACAD_DGNDEFINITIONS&quot;
) ;_ end of list
) ;_ end of mapcar
(command &quot;_.regenall&quot;)
(command &quot;_.externalreferences&quot;)
(princ)
) ;_ end of defun
Open the External Reference Dialog/palette by entering XREF or XR at the command line.
This Picture shows the XREFs in the drawing. There is a JPEG (picture), PDF, & drawing file.
In the picture below:
To detach an xref manually – Select the XREF from the list > right click > select “Detach”
Note: Selecting an xref from the list will highlight that XREF in the drawing area
In the Picture below:
This is how the XREF dialog/Palette looks after running the DETACHALL.lsp or by manually detaching the XREFs from the drawing.
~enjoy
