The title of this post pretty much describes what this routine does. It behaves just like the OFFSET command but it allows you to offset single or multiple segments of a polyline. This pretty cool if you’ve ever needed something like this.

Here’s how to use it:

• OFSEGS <enter> to start
• Specify the offset distance or enter T for the “Through” option
• Select the segments that are to be offset
• Hit <enter> when done selecting segments
• Click on a side to specify what side the objects should be offset

;; OFSEGS -Gilles Chanteau- 2008/03/26

;; Offsets the selected segments of lwpolyline

;; Joined segments are offseted in a single lwpolyline

;; Keeps arcs and widthes

;; Works whatever the current UCS and the pline OCS and elevation

(defun c:ofsegs (/ ofdist ent pline normal elevat params

points side closest par bulge p1

p2 arc_data

)

(vl-load-com)

(or *acdoc*

(setq *acdoc* (vla-get-ActiveDocument (vlax-get-acad-object)))

)

(initget 6 "Through")

(if (setq

ofdist (getdist

(strcat "\nSpecify offset distance or [Through] <"

(if (< (getvar "OFFSETDIST") 0)

"Through"

(rtos (getvar "OFFSETDIST"))

)

">: "

)

)

)

(if (= ofdist "Through")

(setvar "OFFSETDIST" -1)

(setvar "OFFSETDIST" ofdist)

)

(setq ofdist (getvar "OFFSETDIST"))

)

(if (and (setq ent (entsel "\nSelect a segment to offset: "))

(setq pline (vlax-ename->vla-object (car ent)))

(= (vla-get-ObjectName pline) "AcDbPolyline")

(setq normal (vlax-get pline 'Normal))

(setq elevat (vla-get-Elevation pline))

)

(progn

(setq params (cons (fix (vlax-curve-getParamAtPoint

pline

(trans (osnap (cadr ent) "_nea") 1 0)

)

)

params

)

)

(HighlightSegment pline (car params))

(while

(setq ent (entsel "\nSelect next segment or <exit>: "))

(if (equal (vlax-ename->vla-object (car ent)) pline)

(progn

(setq par (fix (vlax-curve-getParamAtPoint

pline

(trans (osnap (cadr ent) "_nea") 1 0)

)

)

params (if (member par params)

(vl-remove par params)

(cons par params)

)

)

(redraw)

(foreach p params (HighlightSegment pline p))

)

)

)

(if (setq side (getpoint

(if (minusp (getvar "OFFSETDIST"))

"\nSpecify through point: "

"\nSpecify point on side to offset: "

)

)

)

(progn

(redraw)

(vla-StartUndoMark *acdoc*)

(setq side (ilp

(trans side 1 0)

((lambda (p)

(trans (list (car p) (cadr p) (1+ (caddr p))) 2 0)

)

(trans side 1 2)

)

(trans (list 0 0 elevat) normal 0)

normal

)

closest (vlax-curve-getClosestPointTo pline side T)

par (vlax-curve-getParamAtPoint pline closest)

)

(if (minusp (getvar "OFFSETDIST"))

(setq ofdist (distance side closest))

)

(cond

((equal closest (vlax-curve-getStartPoint pline) 1e-9)

(setq side (trans side 0 normal))

)

((equal closest (vlax-curve-getEndPoint pline) 1e-9)

(setq par (- par 1)

side (trans side 0 normal)

)

)

((= (fix par) par)

(setq side

(polar

(trans closest 0 normal)

((if

(clockwise-p

(trans

(vlax-curve-getPointAtParam pline (- par 0.1))

0

normal

)

(trans closest 0 normal)

(trans

(vlax-curve-getPointAtParam pline (+ par 0.1))

0

normal

)

)

+

-

)

(angle '(0 0 0)

(trans (vlax-curve-getFirstDeriv pline par)

0

normal

T

)

)

(/ pi 2)

)

ofdist

)

)

)

(T

(setq par (fix par)

side (trans side 0 normal)

)

)

)

(setq bulge (vla-getBulge pline (fix par))

p1 (trans (vlax-curve-getPointAtParam pline (fix par))

0

normal

)

p2 (trans (vlax-curve-getPointAtParam pline (1+ (fix par)))

0

normal

)

)

(if (zerop bulge)

(if (clockwise-p side p2 p1)

(setq ofdist (- ofdist))

)

(progn

(setq arc_data (PolyArc-data bulge p1 p2))

(if (minusp bulge)

(if (< (cadr arc_data)

(distance (car arc_data) side)

)

(setq ofdist (- ofdist))

)

(if (< (distance (car arc_data) side)

(cadr arc_data)

)

(setq ofdist (- ofdist))

)

)

)

)

(mapcar

(function

(lambda (p)

(vl-catch-all-apply 'vla-Offset (list p ofdist))

(vla-delete p)

)

)

(Copysegments pline params)

)

(vla-EndUndoMark *acdoc*)

)

)

)

(princ "\nUnvalid entity.")

)

(princ)

)

;; CopySegments

;; Duplicates polyline segments at the same location

;; Consecutive selected segments are joined

;;

;; Arguments

;; pline : the source polyline (vla-object)

;; params ; the index list of segment to be copied

;;

;; Return

;; the list of created polylines

(defun CopySegments (pline params / nor space tmp copy ret)

(vl-load-com)

(or *acdoc*

(setq *acdoc* (vla-get-ActiveDocument (vlax-get-acad-object)))

)

(setq params (vl-sort params '<)

nor (vlax-get pline 'Normal)

space (vla-ObjectIDToObject *acdoc* (vla-get-OwnerID pline))

)

(while params

(setq tmp (cons (car params) tmp)

params (cdr params)

)

(if (and (zerop (car tmp))

(= (- (vlax-curve-getEndParam pline) 1) (last params))

(equal (vlax-curve-getStartPoint pline)

(vlax-curve-getEndPoint pline)

1e-9

)

)

(progn

(setq params (reverse params)

tmp (cons (car params) tmp)

params (cdr params)

)

(while (= (car params) (1- (car tmp)))

(setq tmp (cons (car params) tmp)

params (cdr params)

)

)

(setq tmp (reverse tmp)

params (reverse params)

)

)

)

(while (= (car params) (1+ (car tmp)))

(setq tmp (cons (car params) tmp)

params (cdr params)

)

)

(setq tmp (reverse (cons (1+ (car tmp)) tmp)))

(setq

pts

(vl-remove nil

(mapcar

(function

(lambda (pa / pt)

(if (setq pt (vlax-curve-getPointAtParam pline pa))

((lambda (p)

(list (car p) (cadr p))

)

(trans pt 0 nor)

)

)

)

)

tmp

)

)

)

(setq copy

(vlax-invoke

space

'addLightWeightPolyline

(apply 'append pts)

)

)

(foreach p (cdr (reverse tmp))

(vla-setBulge

copy

(vl-position p tmp)

(vla-getBulge pline p)

)

(vla-getWidth pline p 'swid 'ewid)

(vla-setWidth copy (vl-position p tmp) swid ewid)

)

(foreach prop '(Elevation Layer Linetype

LinetypeGeneration LinetypeScale

Lineweight Normal Thickness

TrueColor

)

(if (vlax-property-available-p pline prop)

(vlax-put copy prop (vlax-get pline prop))

)

)

(setq tmp nil

ret (cons copy ret)

)

)

)

;;======================================================;;

;; HighlightSegment

;; Highlight a polyline segment

;;

;; Arguments

;; pl : the polyline (vla-object)

;; par : the segment index

(defun HighlightSegment (pl par / p1 p2 n lst)

(and

(setq p1 (vlax-curve-getPointAtParam pl par))

(setq p1 (trans p1 0 1))

(setq p2 (vlax-curve-getPointAtParam pl (+ par 1)))

(setq p2 (trans p2 0 1))

(if (zerop (vla-getBulge pl par))

(grvecs (list -255 p1 p2))

(progn

(setq n 0)

(repeat 100

(setq lst (cons (trans (vlax-curve-getPointAtParam pl (+ n par)) 0 1)

lst

)

n (+ n 0.01)

)

)

(grvecs

(cons -255 (apply 'append (mapcar 'list lst (cdr lst))))

)

)

)

)

)

;;=====================================================;;

;;; Clockwise-p

;;; Returns T if p1 p2 and p3 are clockwise

(defun clockwise-p (p1 p2 p3)

(< (sin (- (angle p1 p3) (angle p1 p2))) -1e-14)

)

;;========================================================;;

;;; Polyarc-data

;;; Returns a list of the center, radius and angle of a 'polyarc'.

(defun polyarc-data (bu p1 p2 / ang rad cen area cg)

(setq ang (* 2 (atan bu))

rad (/ (distance p1 p2)

(* 2 (sin ang))

)

cen (polar p1

(+ (angle p1 p2) (- (/ pi 2) ang))

rad

)

)

(list cen (abs rad) ang)

)

;;====================================================;;

;;; VXV Returns the dot product of two vectors

(defun vxv (v1 v2)

(apply '+ (mapcar '* v1 v2))

)

;;===================================================;;

;;; ILP

;;; Returns the intersection point between a line (extended) and a plane

;;;

;;; Arguments

;;; p1 and p2 : two points defining the line

;;; org : a point on the plane

;;; nor : the plane normal

(defun ilp (p1 p2 org nor / scl)

(setq scl (/ (vxv nor (mapcar '- p1 org))

(vxv nor (mapcar '- p2 p1))

)

)

(mapcar (function (lambda (x1 x2) (+ (* scl (- x1 x2)) x1)))

p1

p2

)

)
